16mm Metal Push Button Switch,On-Off, illuminated, Ring Type LED, latching function, 1NO1NC, 5 Pin
HOUGJU METAL PUSH BUTOONS PB-02A-16 SERIES
(INSTALLATION SIZE:16MM)
Since1998 ,20+ years manufacture experience for metal push buttons
| Place of Origin | Guangdong, China |
| Brand Name | HONGJU |
| Model Number | PB-02A-16-MF |
| Protection Level | IP67 |
| Max. Current | 3A |
| Max. Voltage | 36VDC |
About this item
- Mounting Hole Size: 16mm,Push buttons hole thread:1mm. Mounting Hole.Plaese check the size carfully befor you order it.
- Rated current and voltage:12V 24V 36V 110V 125V 230V 250V.
- Self-Locking Function-Push it to ON ; Push it again to OFF.
- Push button terminal type:screw terminal.Make it easy to install and disassembling.
- Quality after-sales service,if something is not up to your satisfaction, please contact us for a full refund or replacement.
IP PRETECTION GRADE AND IK ENCLOSURE PROTECTION CLASS FOR METAL PUSH BUTTONS IS AVAILABLE
The metal push button can reach to IP67 and IK10 dustproof plastic cover is available
PB-02A-16-RF(16-A6)Normally Closed
PB-02A-16-MR(16-A2)MR Actuator / Screw Terminals
PB-02A-16-MF(16-A4)Short Body / Solder Terminals
PB-02A-16-MF-BOX(16-D4)Ring Type LED
PB-02A-16-MF-XEX(16-C5)Power Marks LED
PB-02A-16-MF-XPX(16-F3)Dot Type LED
PB-02A-16-MF-XQX(16-F5)Ring Type + Power Marks LED
PB-02A-16-MF-XOXX(16-F)Ring Type Dual LED
How to make Order
Please send us an email to specify the item, quantity, color or other specification to place an order.
1. Contact us via website. e-mail. whatsapp etc contacting tools, confirm the model & quantity you want to order with us.
2. Contract will be sent to you.
3. You check the contract and make payment.
4. Package will be delivered to you once we receive the payment.
FAQ
1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
2. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
3. How about your delivery time?
A: Generally, it will take 3 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
4. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
6.What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Product Tags:
|
|
Small 16mm Latching Push Button Switch Metal IP65 Rating Round Shape Images
|
